| Calculates chemical energy demand from 2005 to 2020 from chemical production per route (AllChemicalRoutes_2005to2020) and specific energy consumption for the different routes (retrieved from IEA_PetrochemEI and other literature sources). The energy demand for OtherChem is calculated as the remaining share of total chemical industry energy demand. Results are aggregated to the country level. | calcAllChemicalEnergyDemand_2005to2020 |
| Extrapolates Chemical Flows from 2020 to 2005-2020 based on total chemical UE in 2005-2020 and assuming constant UE shares of the final chemical flows; intermediate ammonia and methanol flows are calculated from the final flows and ammonia-to-fertilizer and methanol-to-hvc ratios. Flows are aggregated to the country level. | calcAllChemicalFlows_2005to2020 |
| Calculates mat2ue conversion factors of ammoFinal, methFinal, HVC and fertilizer for 2020-2150 based on the mat2ue conversion factors in 2020 and the projected relative increases in production (IEA The Future of Petrochemicals) and total chemical UE (FeDemandIndustry) | calcAllChemicalMat2Ue_2020to2150 |
| Calculates chemical route flows (including OtherChem) from 2005 to 2020 from total chemical flows based on 2020 route shares. Flows are aggregated to the country level. | calcAllChemicalRoutes_2005to2020 |
| Filters chemical route flows from calcAllChemicalRoutes_2005to2020 for the year 2020 can be removed if calcAllChemicalRoutes_2005to2020 is read into REMIND | calcAllChemicalRoutes_2020 |
| Calculates chemical energy demand from 2005 to 2020 from chemical production per route (AllChemicalRoutes_2005to2020) and specific energy consumption for the different routes (retrieved from IEA_PetrochemEI and other literature sources). The energy demand for OtherChem is calculated as the remaining share of total chemical industry energy demand. Results are aggregated to the country level. | calcAllChemicalSpecFeDemand_2005to2020 |
| Calculates UE shares for all chemicals (including OtherChem) in 2020 from final product flows (methFinal, ammoFinal, HVC, fertilizer), material prices (mat2ue) and the total UE of chemicals (from FeDemandIndustry). Shares are aggregated to the country level. | calcAllChemicalUeShares_2020 |
| Calculates shares of ammoFinal, methFinal, HVC, fertilizer and OtherChem of total chemical UE for 2020-2150 based on the UE shares in 2020 and the projected relative increases in production (IEA The Future of Petrochemicals) and total chemical UE (FeDemandIndustry) | calcAllChemicalUeShares_2020to2150 |
| Calculates ammonia production volumes per production route in Mt for 2015-2020 based on IFA total ammonia production volumes (2015-2020) and shares for different ammonia production routes from IEA (2020 and 2017) and China specific data (2020) | calcAmmoniaRoute |
| Calculate Historic Cement Production | calcCement |
| Calculate Cement Share in NONMET FE Use | calcCementShare |
| Calculate Chemical Feedstock share projections | calcChemicalFeedstocksShare |
| Aggregates chemical flow data in 2020 from calcAllChemicalRoutes_2020into broader categories based on their outputs (ammonia, methanol, HVC, fertilizer and final ammonia/methanol). | calcChemicalFlows_2020 |
| Joins magpie objects with ammonia, methanol, HVC (Mt) and fertilizer production routes (MtN), calculates ammonia and methanol final routes (Mt that are not used for HVC/fertilizer production), converts from Mt to Gt and returns magpie object for year 2020. | calcChemicalRoutes_2020 |
| Calculate Total Chemical Energy consumption from IEA energy balances (Energy use + Feedstocks) | calcChemicalTotal |
| Retrieve Methanol capacity, Production and consumption data in China from ChinaBaogao (Chinese business website that publishes industry analyses.) | calcChinaBaogao |
| Calculate Clinker-to-Cement Ratio | calcClinkerToCementRatio |
| Calculate emission factors for feedstocks in the chemicals industry using emissions from UNFCCC and energy demands from IEA Energy Balances | calcEmissionFactorsFeedstocks |
| Calculate Energy Balances Output to Industry Additional corrections are applied to the IEA data in [`mrindustry::tool_fix_IEA_data_for_Industry_subsectors`]. | calcEnergyBalancesOutputToIndustry |
| Calculates FE demand in industry as REMIND variables | calcFeDemandIndustry |
| Calculates the total fertilizer production (MtN, as the sum of urea, AN, CAN and AS) per country and the fraction of ammonia production (MtN/MtN) used for fertilizer production based on IFA data. | calcFertilizerRoute |
| Calculate historical basic material production data for steel (Worldsteel) and cement (USGS) | calcHistoricalBasicMaterialProduction |
| Calculate Steel Stock from Mueller steel stock per capita and WDI population | calcHistoricalSteelStock |
| Calculates HVC production volumes per production route in Mt for 2015-2020 based on IEA The Future of Petrochemicals (2018) | calcHVCRoute |
| Read-in IEA Ammonia Technology Roadmap 2021 Fig 2.9 Ammonia production by process route and scenario in major ammonia producing regions data as a magclass object. | calcIEA_Ammonia |
| Read-in IEA The Future of Petrochemicals 2018 data from several figures (e.g., "Fig 4.1 Petrochem Production", "Fig A.1 Petrochem Prod Region", "Fig 4.5 Petrochem Feedstock", "Fig 4.9 Petro Prod Route RTS", "Fig 5.10 Petro Prod Route CTS") as a MagPIE object. | calcIEA_Petrochem |
| Retrieve specific energy consumption (SEC) for the production of key chemicals (2006) from IEA Information Paper Chemical and Petrochemical Sector 2009 (Table 12) | calcIEA_PetrochemEI |
| Retrieve IFA (International fertilizer Association) data containing production, consumption, export and import volumes as well as capacities for ammonia and urea. | calcIFA_Chem |
| Retrieves IFA (International fertilizer Association) data containing production volumes and/or capacities for ammonium nitrate (AN), ammonium sulphate (AS), calcium ammonium nitrate (CAN) and urea ammonium nitrate (UAN). | calcIFA_ChemAppend |
| Retrieve methanol production, capacity and demand data for 2018 from 9TH RUSSIA & CIS OIL & GAS EXECUTIVE SUMMIT 2019 METHANOL, optionally the 2018 data is interpolated to 2010-2020 based on temporal coverage of Methanol capacities 2010-2020 from IHS Markit | calcIHS_Meth |
| Calculate Limits on Industry CCS Capacities | calcIndustry_CCS_limits |
| Industry Energy Efficiency Capital | calcIndustry_EEK |
| Calculate Maximum Secondary Steel Production Share | calcindustry_max_secondary_steel_share |
| Thermodynamic Limits for Industry Specific FE Demand | calcindustry_specific_FE_limits |
| Function for calculating industry activity trajectories. | calcIndustry_Value_Added |
| Calculate different feedstocks for the chemical sector from IEA energy balances | calcIndustryFE |
| Calculates methanol production volumes per production route in Mt for 2015-2020 based on methanol production volumes (Argus 2018 data, extrapolated to 2015-2020 based on IHS data, and China specific data 2015-2020) and shares for different methanol production routes from IEA (2017) and China specific data (2020) | calcMethanolRoute |
| Read-in MMSA Global Methanol Outlook 2023 Growth and Decarbonization data containing regional methanol capacities and demands. | calcMMSA_Methanol |
| Read-in RMI (Rocky Mountain Institute) "Transforming China Chemicals Industry Pathways and Outlook under the Carbon Neutrality Goal 2022.xlsx" data from either "ES1-3 China Chemical Demand" or "ES29 China Chemical Structure" sheets as a magclass object. Data contains chemical demand projections 2020-2050 for ammonia, methanol and ethylene and the feedstock structure for the production of ammonia, methanol and ethylene in the zero-carbon scenario. | calcRMI_China |
| Function for calculating industry activity trajectories. | calcSteel_Projections |
| Convert ADVANCE WP2 Data | convertADVANCE_WP2 |
| Convert ChinaBaogao | convertChinaBaogao |
| Convert IEA_Ammonia | convertIEA_Ammonia |
| Convert IEA_Petrochem | convertIEA_Petrochem |
| Convert IEA_PetrochemEI | convertIEA_PetrochemEI |
| Convert IFA_Chem | convertIFA_Chem |
| Convert IFA_Chem | convertIFA_ChemAppend |
| Convert IHS_Meth | convertIHS_Meth |
| Convert MMSA_Methanol | convertMMSA_Methanol |
| Convert Mueller data | convertMueller |
| Convert RMI_China | convertRMI_China |
| convertStegmann2022 | convertStegmann2022 |
| Read ADVANCE WP2 Data | readADVANCE_WP2 |
| Read ChinaBaogao | readChinaBaogao |
| Read IEA_Ammonia | readIEA_Ammonia |
| Read IEA_Petrochem | readIEA_Petrochem |
| Read-in specific energy consumption (SEC) for the production of key chemicals (2006) from IEA Information Paper Chemical and Petrochemical Sector 2009 (Table 12) | readIEA_PetrochemEI |
| IEA World Energy Investment Outlook (2014) | readIEA_WEIO_2014 |
| Read IFA | readIFA_Chem |
| Read IFA | readIFA_ChemAppend |
| Read IHS_Meth | readIHS_Meth |
| industry/subsector change factors | calcindustry_subsectors_specific readindustry_subsectors_specific |
| Read MMSA_Methanol | readMMSA_Methanol |
| Read Müller et al. 2013 data. | readMueller |
| Read ODYM_RECC data from the SHAPE Project | calcODYM_RECC readODYM_RECC |
| Read Pauliuk et al. 2013 data | readPauliuk |
| Read RMI_China | readRMI_China |
| Read PlasticsEoL | readStegmann2022 |
| UNIDO data | calcUNIDO convertUNIDO readUNIDO |
| Read U.S. Geological Survey data | convertUSGS readUSGS |
| Read van Ruijven et al. (2016) data. | readvanRuijven2016 |
| Read World Steel Statistical Yearbook Data | readworldsteel |
| Expand tibble across scenarios and regions with default values | tool_expand_tibble |
| Apply adjustments to industry-related IEA data | tool_fix_IEA_data_for_Industry_subsectors |
| convergence year and level (relative to global average) to which per-capita cement demand converges (Michaja Pehl) | toolGetCementConvergenceParameters |
| Steel production estimates (Michaja Pehl) | toolGetExpertGuessSteelProduction |
| Maximum share of secondary steel production in total steel production and years between which a linear convergence from historic to target shares is to be applied. (Michaja Pehl) | toolGetSecondarySteelShare |
